A large-bore NGT is placed. Is placement confirmed?
Correct! We can see the large-bore NGT bisect the left mainstem bronchus, course through the G-E junction, and finally pass much below the diaphragm. Because this is a large-bore tube, we also have to pay attention to the location of the sidehole port. We can also see here that the sidehole port also goes past the G-E junction and is itself below the diaphragm and in the stomach. This tube can now be used.
Sorry! This tube is actually appropriate for use and can be confirmed. We can see the large-bore NGT bisect the left mainstem bronchus, course through the G-E junction, and finally pass much below the diaphragm. Because this is a large-bore tube, we also have to pay attention to the location of the sidehole port. We can also see here that the sidehole port also goes past the G-E junction and is itself below the diaphragm and in the stomach.
